Industrial 20.1" Flat Panel Monitor 31
Publication 6185-5.2
Specifications
Display
Type Active Matrix Color Thin Film Transistor (TFT) LCD
Backlight
Type
Life Expectancy
Field Replaceable
Cold Cathode Tube (CCT)
17,500 hours (typical)
No
Nominal Display Area
Horizontal
Vertical
15.7in. (399mm)
12.6in. (319mm)
Resolution 1280x1024 pixels, full color
Viewing Angle
Horizontal (typical)
Vertical (typical)
+/-80deg.
+/-80deg.
Luminance (typical) 130 nit, 38 fL
Contrast Ratio (typical) 100:1
CIE coordinates
White x=0.291, y=0.338
Response Time 130 msec (typical)
Video
Supported Standards 720x400 at 70 Hz (VGA text)
640x480 at 60Hz and 75Hz
800x600 at 60Hz and 75Hz
1024x768 at 60Hz and 75Hz
1280x1024 at 60Hz and 75Hz (native)
Video Input Signal RGB analog (white level = 0.714V above ref. Black,
into 75 Ohms
Sync Input Signals H and V separate (TTL levels, positive or negative)
Input Connection HD-15
Controls and Indicators
Front Panel Luminance (optional)
Back Panel Horizontal Size, Vertical Position, Horizontal Position,
Contrast, Brightness, Clock Phase, Backlight
Operator Input Touchscreen Option - Resistive or capacitive
touchscreen, with serial controller and DOS and
Windows drivers
Electrical
Line Voltage 85 to 264VAC, or 18 to 32VDC
Line Frequency 47-70Hz or DC
Ground Leakage 1.0 uA max at 1.5KVDC
Power Consumption 85W max, 100 VA
