Component List

Following is a complete list of components included in this kit:

Item Number

Description

Qty

192454-9

Drawing - RGU, 3rd LEM kit

1

192454-EB

Engineering Bill of Materials

1

192667

Manual - “Insert Spare RGU Power Structure” 2364F-5.20

1

22530-907-01 Ferrite Core

1

317809

Relay - GP RY42S Min. w/Pilot Light

1

139663

Socket Relay - 14 Blade for B type HC Relay, Series B

1

127107

Spring-Clip Relay - Hold-down, type HC & HF32 Relay

1

135127

Resistor - 1.0W, 215 Ohm, MF, 1%

1

173205

Resistor - MF 4.02 Ohm, 1W, 1%, Axial

1

173206

Resistor - 1W, MF, 4.53 Ohm, 0.5%

1

173203

Resistor - 1W, MF, 3.01 Ohm, 0.5%

1

173204

Resistor - MF, 3.40 Ohm, 1W, 0.5%

1

192420

Assembly PCB - RGU Isolation Board

1

192639

Kit, PCB - RGU Main Control 3 LEM w/revision 3.xx firmware

1

157907

DC Power Supply - Dual Output +/-15Vdc, 1.6A, UL

1

25503-011-01 Current Transducer - 1:4000 1500A

1

192424

Assembly - PCB Gate Driver Board Power Supply Filter

1

136019

Standoff - M/F 6m x 13mm long 4 x 0.7m Threaded Aluminum

4

192422

Wire Harness Assembly - Power Supply to LEMS, RGU, G-H Frm, Serb.

1

22112-114-04 Terminal Block -Terminal Block Screw, Clamp 2 pos.

1

192396

Terminal Bus for LEM PCB - 500HP Drive, Bulletin 1336

3

74103-863-02 Panel - Front Door Frame, 800HP Drive, Bulletin 1336

1

192397

Glastic Support for LEM PCB - 500HP Drive, Bulletin 1336

1

192418

Bracket - PCB, Common Mode

1

192398

Lexan Guard for LEM PCB - 500HP Drive, Bulletin 1336

1

192425

Guard, Lexan - PCB DC Bus Torroid

1

192419

Insulator - PCB, Common Mode

1

113246

Tubing - Insulated #16 PVC Clear .053 ID, .016 Wall

6

74101-570-01 Label - Servicing, Bulletin 1336, 60-125HP

1

74101-519-01 Nameplate - 1” x 3” White Thermal Printer

1

74101-511-01 Mylar Insulator

1

22805-031-06 Spacer - Board Support, Nylon 1.00” x 0.156”

5

201754

Box - Cardboard, 12” x 9” x 2” with Anti-Static Foam

1

173629

Package Box - Corrugated Kit, 4.5 x 4.13 x 4.88 Systems Drive

1

109842

Screw - Pan Phillips head, 8 - 32 x .38 SEMS, YEL CHR

4

29164-201-05 Screw - Pan head, Steel, SEMS M4 x 0.7 x 12mm

4

29164-201-06 Screw - Pan head, Steel, SEMS M4 x 0.7 x 24mm

2

419064-1SG

Washer - Flat, M4 Steel Per DIN 125A

4

140300

Nut - KEPS M4 x 0.7

4

29164-251-01 Screw - Pan Head, Steel, SMES M5 x 0.8 x 10mm

4

419064-1HJM Screw - Washer Head, M6 x 25mm Grade 4.8+, Zinc

8

22805-057-02 Spacer - Board, 1/4 Turn ML Polysulfone, 0.25” x 0.952”

20
