Page 3: Installation instructions

Publication 2711P-IN008C-MU-P - March 2007
Installation Instructions
Compact Flash Cards
Catalog Numbers 2711P-RC2, 2711P-RC2, 2711P-RC3, 2711P-RCH
English
Application
CompactFlash Cards are a storage medium for 2711P PanelView Plus or
PanelView Plus CE terminals.
The card slides into the CompactFlash slot of the terminal, or into a PCMCIA slot of
a personal computer using an adapter, 2711P-RCH.
Install a Memory Card
1. Locate the card slot on the side of the terminal.
ATTENTION
Do not subject the memory card to moisture, extreme temperatures, direct
sunlight, flexing or extreme pressure. Failure to observe this caution could
result in damage to the card.
CF card slot
Eject button
