Rockwell Automation 1734-OX2/C POINT I/O 2 Relay Output Module - Manual (Page 19)

POINT I/O 2 Relay Output Module 19
Publication 1734-IN587B-EN-P - March 2002
Fusing Module outputs are not fused. If fusing is desired, you
must supply external fusing.
Indicators 2 green/red module/network status
2 yellow output status
Keyswitch position 7
General Specifications
Module Location 1734-TB or -TBS wiring base assembly
Pointbus Current 100mA max @ 5V dc
Power Dissipation 0.5W max
Thermal Dissipation 1.7 BTU/hr max
Isolation Voltage
Between any 2 sets
of contacts
Customer load to logic 250V continuous (Tested to 2550V dc for 1s)
250V continuous (Tested to 2550V dc for 1s)
Field Power Bus
Supply Voltage
Voltage Range
Supply Current None required
240V ac max
2A per channel maximum, 4A per module
Dimensions Inches
(Millimeters)
2.21H x 0.47W x 2.97L
(56H x 12W x 75.5L)
Environmental Conditions
Operational Temperature IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20 to 55°C (-4 to 131°F)
Storage Temperature IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry
Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating
Thermal Shock):
-40 to 85°C (-40 to 185°F)
Relative Humidity IEC 60068-2-30 (Test Db, Unpackaged Nonoperating
Damp Heat):
5 to 95% noncondensing
Shock
Operating
Non-operating
IEC60068-2-27 (Test Ea, Unpackaged Shock)
30g peak acceleration
50g peak acceleration
Vibration IEC60068-2-6, (Test Fc, Operating)
Tested 5g @ 10-500Hz
ESD Immunity IEC 61000-4-2:
6kV contact discharges
8kV air discharges
Radiated RF Immunity IEC 61000-4-3:
10V/m with 1kHz sine-wave 80%AM from 80MHz to
1000MHz
10V/m with 200Hz 50% Pulse 100%AM at 900Mhz
