Remote I/O Adapter Module 9
Publication 1747-IN014C-EN-P - January 2003
IMPORTANT
If you are not using complementary I/O, you must set SW2-3 to
the OFF, or complementary, position.
1
O N
24
5
6
7
8
3
SW2
Baud Rate Bit 1 (MSB)
Baud Rate Bit 0 (LSB)
Primary/Complementary Chassis
Reserved
ASB Module Image Size Bit 3 (MSB)
ASB Module Image Size Bit 2
ASB Module Image Size Bit 1
ASB Module Image Size Bit 0
Baud Rate
SW2-1 SW2-2 Baud Rate
ON ON 57.6K (default)
ON OFF 115.2K
OFF ON 230.4K
OFF OFF INVALID
Primary/Complementary Chassis
ON Primary
OFF Complementary
1747-ASB Module Image Size
5 6 7 8 Groups
ON ON ON ON 2
ON ON ON OFF 4
ON ON OFF ON 6
ON ON OFF OFF 8
ON OFF ON ON 10
ON OFF ON OFF 12
ON OFF OFF ON 14
ON OFF OFF OFF 16
OFF ON ON ON 18
OFF ON ON OFF 20
OFF ON OFF ON 22
OFF ON OFF OFF 24
OFF OFF ON ON 26
OFF OFF ON OFF 28
OFF OFF OFF ON 30
OFF OFF OFF OFF 32
