ArmorBlock 8 Input Module
Publication 1792-5.2 – October 1996
0,
$ reserved
6,
$ Link Path Size
”20 08 24 03 30 03”,
$ Link Path to Input 3 value attribute.
0x0030,
$ No support for settable path, scaling, or scaling
$ links.
$ Value is gettable only.
$ Enumerated strings are not supported.
8,
$ Data Type – unsigned short int
1,
$ Data Size – (in bytes)
”Input 3 Value”,
$ Parameter Name
””,
$ Units String
$$$$$$$$$$ Help string $$$$$$$$$$$
”This parameter is the current value of Input 3.”,
0,1,0,
$ Min, Max, and Default values
1,1,1,0,0,0,0,0,0;
$ Not Used
$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$
$$$$$$$$$$
Param8 =
$ Input 4 value
0,
$ reserved
6,
$ Link Path Size
”20 08 24 04 30 03”,
$ Link Path to Input 4 value attribute.
0x0030,
$ No support for settable path, scaling, or scaling
$ links.
$ Value is gettable only.
$ Enumerated strings are not supported.
8,
$ Data Type – unsigned short int
1,
$ Data Size – (in bytes)
”Input 4 Value”,
$ Parameter Name
””,
$ Units String
$$$$$$$$$$ Help string $$$$$$$$$$$
”This parameter is the current value of Input 4.”,
0,1,0,
$ Min, Max, and Default values
1,1,1,0,0,0,0,0,0;
$ Not Used
$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$
$$$$$$$$$$
Param9 =
$ Input 5 value
0,
$ reserved
6,
$ Link Path Size
”20 08 24 05 30 03”,
$ Link Path to Input 5 value attribute.
0x0030,
$ No support for settable path, scaling, or scaling
$ links.
$ Value is gettable only. Enumerated strings are not
$ supported.
8,
$ Data Type – unsigned short int
1,
$ Data Size – (in bytes)
”Input 5 Value”,
$ Parameter Name
””,
$ Units String
$$$$$$$$$$ Help string $$$$$$$$$$$
”This parameter is the current value of Input 5.”,
0,1,0,
$ Min, Max, and Default values
1,1,1,0,0,0,0,0,0;
$ Not Used
$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$
$$$$$$$$$$
Param10 =
$ Input 6 value
0,
$ reserved
6,
$ Link Path Size
”20 08 24 06 30 03”,
$ Link Path to Input 6 value attribute.
