Rockwell Automation 1738-AENTR Armorpoint 2 Port Enet Adapter User Manual
Page 18
18 ArmorPoint I/O 2-Port EtherNet/IP Adapter, Series A
Publication
1738-IN028B-EN-E - February 2010
Weight, approx.
0.33 kg (0.72 lb)
Mounting type
Metal panel
Enclosure type rating
Meets IP65/66/67/69K (when marked)
(1)
Refer to publicat
r more information.
(2)
Use this Conductor Category information for planning conductor routing. Refer to Industrial
Automation Wiring and Grounding Guidelines, publication
Specifications for Ethernet Communication
Attribute Value
Ethernet communication rate
10/100 Mbps, half or full-duplex
Ethernet ports
2, configured as Embedded Switch
Ethernet network topologies
supported
Star, Tree, Daisy chain/Linear, and Ring
Ethernet connector
M12, D code, female, with Ethernet keying
Ethernet cable
Category 5: Shielded or unshielded
General (Continued)
Attribute
Value
