Multi-Channel High-Speed Counter 17
Publication 1746-IN002A-US-P
Inputs A, B, and Z
Jumper Setting 5V dc 24V dc
Nominal Input Voltage 5V dc 24V dc
Input Voltage Range 4.2V dc to 12V dc 10V dc to 30V dc
On-State Voltage (min.) 4.2V 10V
Off-State Voltage (max.) 0.8V 3V
Maximum Off-state Leakage
Current 100 µA 100 µA
Input Current (max.) 8 mA 20 mA
Input Current (min.) 6.3 mA 6.3 mA
Nominal Input Impedance 500
Ω
1500
Ω
Min. Pulse Width 475 ns 475 ns
Min. Phase Separation 200 ns 200 ns
Max. Input Frequency 1 MHz 1 MHz
Isolation (from backplane) 1000V 1000V
Isolation (from outputs) 500V 500V
