12 ControlLogix SERCOS interface Module
Publication 1756-IN572G-EN-P - May 2005
Fiber Optic Cables
ATTENTION
Under certain conditions, viewing the optical port may expose
the eye to hazard. When viewed under some conditions, the
optical port may expose the eye beyond the maximum
permissible exposure recommended in ANSI Z136.2, 1993.
Table 4 Choose a Plastic Fiber Optic Cable
For use in: Use this type of
plastic cable: Length in meters
(inches) Allen-Bradley
Catalog Number
electrical cabinet non-jacketed
(Chlorinated
Polyethylene) 1 m (39 in) 2090-SCEP1-0
3 m (118 in) 2090-SCEP3-0
5 m (197 in) 2090-SCEP5-0
8 m (315 in) 2090-SCEP8-0
10 m (394 in) 2090-SCEP10-0
15 m (591 in) 2090-SCEP15-0
20 m (787 in) 2090-SCEP20-0
25 m (984 in) 2090-SCEP25-0
32 m (1260 in) 2090-SCEP32-0
normal
environments
outside of an
electrical cabinet standard jacket
(Polyvinyl Chloride) 1 m (39 in) 2090-SCVP1-0
3 m (118 in 2090-SCVP3-0
5 m (197 in) 2090-SCVP5-0
8 m (315 in) 2090-SCVP8-0
10 m (394 in) 2090-SCVP10-0
15 m (591 in) 2090-SCVP15-0
20 m (787in) 2090-SCVP20-0
25 m (984 in) 2090-SCVP25-0
32 m (1260 in) 2090-SCVP32-0
