POINT I/O 120/240V ac Expansion Power Supply 13
Publication 1734-IN017A-EN-P - December 2005
Specifications
Specifications - 120/240V ac Expansion Power Supply, Cat. No. 1734-EPAC
I/O Module Capacity 12 modules typical (depending on current draw and orientation
of modules; 4 to 17 based on module current requirements -
total not to exceed 1.3 A) (for example, 5 modules at 0.220 A;
17 modules at 0.075 A)
Cat. No.
PointBus Current Requirements
1734-IB2 75 mA
1734-IB4 75 mA
1734-IB8 75 mA
1734-IV2 75 mA
1734-IV4 75 mA
1734-OB2 75 mA
1734-OB4 75 mA
1734-OB8 75 mA
1734-OB2E 75 mA
1734-OB2EP 75 mA
1734-OB4E 75 mA
1734-OB8E 75 mA
1734-OV2E 75 mA
1734-OV4E 75 mA
1734-OW2 80 mA
1734-OX2 100 mA
1734-IE2C 75 mA
1734-OE2C 75 mA
1734-IE2V 75 mA
1734-OE2V 75 mA
1734-IA2 75 mA
1734-IM2 75 mA
1734-OA2 75 mA
1734-IJ2 160 mA
1734-IK2 160 mA
1734-IR2 220 mA
1734-IT2I 175 mA
1734-SSI 110 mA
1734-VHSC5 180 mA
1734-VHSC24 180 mA
1734-232ASC 75 mA
1734-485ASC 75 mA
Input Voltage Rating 120/240V ac nom, 50…60 Hz
85…264V ac range
Field Side Power
Requirements 120V ac at 200 mA max
240V ac at 100 mA max
Inrush Current 2 A max for 6 ms
Indicators 1 green field power status indicator
1 green 5V system power indicator
