20 1734 POINT I/O EtherNet/IP Adapter
Publication 1734-IN042B-EN-P - October 2013
Input overvoltage protection
Reverse polarity protected
POINTBus output current, max
5V DC @ 1.0A
Interruption
Output voltage will stay within specifications when input drops
out for 10ms at 10V with maximum load.
Ethernet Communication
Attribute
Value
Ethernet communication rate
10/100 Mbits/s, half or full-duplex
Ethernet ports
1
Ethernet network topologies supported
Star, Tree
Ethernet connector
RJ-45, Category 5
Ethernet cable
Category 5:
shielded or unshielded
Ethernet wire connections, max
See
General Specifications
Attribute
Value
Indicators
3 red/green status indicators (on CPU):
– Module status
– Network status
– POINTBus status
1 green status indicator on CPU:
– Network activity
2 green power supply status indicators on DC-DC Converter:
– System power (5V DC to POINTBus Out)
– Field power (24V DC from Field In)
Power consumption, max
4.5W @ 28.8V DC
Power dissipation, max
15.5W @ 28.8V DC
Thermal dissipation, max
9.5 BTU/hr @ 28.8V DC
Isolation voltage
50V (continuous), Reinforced Insulation Type, between
all circuits.
Type tested at 500V AC for 60 s
Field power supply
10...28.8V DC @ 10A
Field power output
10...28.8V DC @ 9A
Power Supply
Attribute
Value
