Rockwell Automation 1760-Lxxxx Pico Controller Installation Instructions User Manual
Page 15
15/20
Fitting – Montage – Montaggio – Montaje
on 35 mm DIN rail
auf 35-mm-Hutschiene
sur profilé-support 35 mm
su guida DIN 35 mm
sobre guía semétrica de 35 mm
on mounting plate (horizontal)
auf Montageplatte (waagerecht)
sur plaque de montage (horizontal)
su piastra di montaggio (orizzontale)
sobre placa de montaje (horizontal)
1760-NMF
Mounting position – Einbaulage – Position de montage – Posizione di montaggio –
Posición de montaje
with DIN rail (horizontal and vertical) – mit Hutschiene (waagerecht und senkrecht) – sur profilé chapeau
(horizontale et verticale) – su guida DIN (orizzontale e verticale) – sobre carril (horizontal y vertical)
1
2
a
a
a
a
CLICK !
3 mounting feet sufficient
3 Gerätefüße ausreichend
3 pattes de fixation suffisent
3 piedini di fissaggio sufficienti
3 pies de sujeción adecuados
30
30
1.18“
1.18“
30
30
1.18“
1.18“
Pub_IN002C_0907Brandlabel_AB_AWA1739.FM Seite 15 Donnerstag, 15. November 2007 6:35 18
