POINT I/O One-piece Terminal Bases 7

Publication 1734-IN028B-EN-P - April 2010

Specifications

One-piece Terminal Bases -

1734-TOP, 1734-TOPS, 1734-TOP3, 1734-TOP3S

Attribute

Value

Dimensions
(HxWxD),
Approx.

1734-TOP, 1734-TOPS 49 x 12 x 144 mm (1.93 x 0.47 x 5.67 in.)

1734-TOP3, 1734-TOP3S 49 x 12 x 168 mm (1.93 x 0.47 x 6.61 in.)

Weight,
Approx.

1734-TOP 63.8 g (2.25 oz), 1734-TOP3 79.2 g (2.79 oz),

1734-TOPS 55.68 g (1.96 oz), 1734-TOP3S 66.8 g (2.36 oz)

Wire Size

0.25... 2.5 mm² (22...14 AWG) solid or stranded copper wire rated at 75 °C
(167 °F ), or greater, 1.2 mm (3/64 in.) insulation max

Category

Dependent on I/O module installed in terminal base

(1)

(1)

Use this conductor category information for planning conductor routing as described in Industrial
Automation Wiring and Grounding Guidelines, publication 1770-4.1.

Supply voltage

300V max terminal voltage

Supply power

8A max terminal current

Isolation
Voltage

Capable of 240V (continuous), Reinforced Insulation Type, or the lesser of the
installed module.

Enclosure Type
Rating

None (open-style)

Field Power
Bus Supply
Voltage

28.8V DC, 120/240V AC

Terminal Base
Screw Torque

1734-TOP and 1734-TOP3 0.6 Nm (7 lb-in)

Terminal block
torque

0.4Nm (3.5 lb-in) for 1734-TOP and 1734-TOP3 only
