P–2 Using This Manual
Publication 1794Ć6.5.2 - May 1996
We use these conventions in this manual:
In this manual, we show: Like this:
that there is more information about a topic
in another chapter in this manual
that there is more information about the
topic in another manual
More
For additional information on FLEX I/O systems and modules, refer
to the following documents:
Catalog
Publications
Catalog
Number
Voltage Description
Installation
Instructions
User
Manual
1794 1794 FLEX I/O Product Data 1794Ć2.1
1794ĆACN 24V dc ControlNet Adapter 1794Ć5.8
1794ĆADN 24V dc DeviceNet Adapter 1794Ć5.14 1794Ć6.5.5
1794ĆASB 24V dc Remote I/O Adapter 1794Ć5.11 1794Ć6.5.3
1794ĆTB2
1794ĆTB3
2Ćwire Terminal Base
3Ćwire Terminal Base
1794Ć5.2
1794ĆTBN Terminal Base Unit 1794Ć5.16
1794ĆTBNF Fused Terminal Base Unit 1794Ć5.17
1794ĆTB3T Temperature Terminal Base Unit 1794Ć5.41
1794ĆIB16 24V dc 16 Input Module 1794Ć5.4
1794ĆOB16 24V dc 16 Output Module 1794Ć5.3
1794ĆIB10XOB6 24V dc 10 Input/6 Output Module 1794Ć5.24
1794ĆIE8 24V dc Selectable Analog 8 Input Module 1794Ć5.6
1794ĆOE4 24V dc Selectable Analog 4 Output Module 1794Ć5.5 1794Ć6.5.2
1794ĆIE4XOE2 24V dc 4 Input/2 Output Analog Module 1794Ć5.15
1794ĆIR8 24V dc 8 RTD Input Analog Module 1794Ć5.22 1794Ć6.5.4
1794ĆIT8 24V dc 8 Thermocouple Input Module 1794Ć5.21 1794Ć6.5.7
1794ĆIB8S 24V dc Sensor Input Module 1794Ć5.7
1794ĆIA8 120V ac 8 Input Module 1794Ć5.9
1794ĆOA8 120V ac Output Module 1794Ć5.10
1794ĆCE1 Extender Cable 1794Ć2.12
1794ĆNM1 Mounting Kit 1794Ć2.13
1794ĆPS1 24V dc Power Supply 1794Ć5.35
Conventions
For Additional Information
