1747-SDN DeviceNet Scanner Module 9
Publication 1747-IN058F-EN-P - December 2010
440.646.5800. To install the kit, refer to the ControlFLASH Firmware Upgrade Kit User
Manual, publicat
Confirm Processor and Adapter Compatibility
Make sure that your processor and adapter are compatible. You can use the 1747-SDN
scanner module in any slot in an I/O chassis except for the leftmost, which is reserved for the
SLC 500 processor.
Install DeviceNet Scanner Module
Follow these steps to install the module.
1.
Turn off the chassis power supply.
2.
Select a slot for the module in the chassis.
You may use any slot except the leftmost slot, which is reserved for the SLC 500
processor.
IMPORTANT
You can update Series A and B scanner modules up to FRN 7.006. Series C
scanner modules support only FRN 8.001 to 8.006. Series D scanner modules
support FRN 9.001 and later.
IMPORTANT
You cannot use the scanner module in a remote I/O chassis with a 1747-ASB
adapter module. The adapter module does not support M-file transfer.
WARNING
If you insert or remove the module while backplane power is on, an electrical
arc can occur. This could cause an explosion in hazardous location installations.
Be sure that power is removed or the area is nonhazardous before proceeding.
