MicroLogix 1400 Programmable Controllers 31
Publication 1766-IN001C-EN-P - October 2009
1766-L32BXB, 1766-L32BXBA FET Output
Maximum output current (temperature dependent):
Maximum Volts Amperes Amperes
Continuous Volt-Amperes
Make Break Make Break
240V AC 7.5 A 0.75 A 2.5 A 1800 VA 180 VA
120V AC 15.0 A 1.5 A 2.5 A 1800 VA 180 VA
250V DC 0.11 A 1.0 A 28 VA
125V DC 0.22 A 1.0 A 28 VA
Description General Operation
High Speed Operation (1)
(Output 2, 3 and 4 Only)
Power supply voltage 24V DC (-15%, 10%) Class 2
On-state voltage drop:
at max load current
at max surge current
1V DC
2.5V DC Not Applicable
Not Applicable
Current rating per point
max load
min load
max leakage
See graphic above
1.0 mA
1.0 mA
100 mA
20 mA
1.0 mA
Surge current per point:
peak current
max surge duration
max rate of repetition @ 30 °C (86 °F)
max rate of repetition @ 60 °C (140 °F)
4.0 A
10 ms
once every second
once every 2 seconds Not Applicable
Not Applicable
Not Applicable
Not Applicable
0.25
10°C
(50°F)
30°C
(86°F)
50°C
(122°F)
0.75A, 60°C (140°F)
1.5A, 30°C (86°F)
70°C
(158°F)
80°C
(176°F)
0.5
0.75
1.0
1.25
1.5
1.75
2.0
1.0
10°C
(50°F)
30°C
(86°F)
50°C
(122°F)
3.0A , 60°C (140°F)
6.0A , 30°C (86°F)
70°C
(158°F)
80°C
(176°F)
2.0
3.0
4.0
5.0
6.0
7.0
8.0
FET Current per Point FET Total Current
Current (A
mp
s)
Current (A
mp
s)
Temperature Temperature
Valid
Range Valid
Range
