Alphanumeric display codes – Rockwell Automation 1756-DHRIOXT ControlLogix-XT Data Highway Plus-Remote I/O Communication Interface Module User Manual
Page 21
ControlLogix-XT Data Highway Plus-Remote I/O Interface Module 21
Publication
1756-IN638A-EN-P - March 2009
Alphanumeric Display Codes
Your 1756-DHRIOXT module displays alphanumeric codes that
provide diagnostic information. The alphanumeric display flashes the
codes at approximately 1-second intervals. These tables describe
codes and interpretations specific to the application of the module.
Data Highway Plus Codes and Interpretations
Code
Description
Recommended Action
OFF
LINE
Data Highway Plus link is in
STOP state.
DUPL
NODE
Data Highway Plus Duplicate
node address.
Choose another node address and reset
switches.
ONLY
NODE
Only node on Data Highway
Plus link.
Check the cables.
CNFG
FALT
Incorrect DH+ routing table
configuration.
Incorrect Data Highway
object configuration.
•
•
Verify that the module is inserted in
the correct slot.
OK
Normal operation for that
channel.
None.
LINK
OFF
Channel B is disabled
because Channel A is used
for 230k DH+ operation.
None.
