PICO™ Programming
PROGRAM. . .
STOP
PARAMETER
SET CLOCK. . .
Saving & Running your
program
Press the ESC button to save
the program to memory.
Press the Esc button again to
take you to the Main menu.
Press P4 to go to “RUN”
mode. Press Okay.
(see screen to left)
Press the Esc button to take
you to the front display.
In Run Mode
Press the Start button. This will SET Output #6 which picks
up the coil in the contactor and turns on the green pilot
light. At the same time, it also starts a 10 second timer.
Once that timer has completed, it will RESET Output #6
and drops the coil in the contactor, which turns off the
pilot light.
OPTIONAL Steps
While on the front display press the OK button twice.
You will be able to see the program while in Run mode.
You can notice what rungs are active by noticing the
highlighted rungs.
Press Esc, press P2 twice to highlight the Parameter
button. Press OK. You will now be monitoring the T1 timer.
Press the Start button to see the timer count up to 10.
In this mode you can also change the Preset value
of the timer.
Congratulations, you have successfully
programmed the PICO Controller!
