1768 CompactLogix Power Supplies 29
Publication 1768-IN001B-EN-P - July 2006
Surge Transient Immunity
IEC 61000-4-5:
• ±2 kV line-line (DM) and ±4 kV
line-earth (CM) on ac power
ports
• ±1 kV line-line (DM) and ±2 kV
line-earth (CM) on dc power
ports
IEC 61000-4-5:
±1 kV line-line (DM) and ±2 kV
line-earth (CM) on dc power ports
Temperature, Operating
IEC 60068-2-1 (Test Ad, Operating Cold)
IEC 60068-2-2 (Test Bd, Operating Dry Heat)
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
0…60 °C (32…140 °F)
Temperature, Storage
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold)
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat)
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock):
-40…85 °C (-40…185 °F)
Vibration
IEC 60068-2-6 (Test Fc, Operating):
5 g @ 10…500 Hz
Voltage Variation
IEC 61000-4-11:
• 30% dips for 1 period at 0° &
180° on ac supply ports
• 60% dips for 5 & 50 periods
on ac supply ports
• ±10% fluctuations for 15 min
on ac supply ports
• > 95% interruptions for 250
periods on ac supply ports
IEC 61000-4-29:
• 60% dip for 100 ms on dc
supply ports
• 30% dip for 10 ms on dc
supply ports
• 100% dip for 10 ms on dc
supply ports
• ±20% fluctuations for 15 min
on dc supply ports
• 5 s interruptions on dc supply
ports
Environmental Specifications
Attribute
1768-PA3
1768-PB3
