20 Enhanced PLC-5 Programmable Controllers
Controller Specifications
General Specifications
Backplane Current
PLC-5/11, -5/20, -5/30: 2.3A @ 5Vdc
PLC-5/40, -5/40L, -5/46, -5/60, -5/60L, -5/80, -5/86: 3.3A @ 5Vdc
Isolation Voltage
Communication Ports - tested to 500V for 60 seconds
Relay Cartridge - tested to 1000V for 60 seconds
Operating Temperature
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
0-60
o
C (32–140
o
F)
Storage Temperature
IEC 60068-2-1 (Test Ab, Un-packaged Non-operating Cold),
IEC 60068-2-2 (Test Bc, Un-packaged Non-operating Dry Heat),
IEC 60068-2-14 (Test Na, Un-packaged Non-operating Thermal Shock):
–40 to 85
o
C (–40 to 185
o
F)
Relative Humidity
IEC 60068-2-30 (Test Db, Un-packaged Non-operating
Damp Heat):
5–95% non condensing
Vibration
IEC60068-2-6 (Test Fc, Operating):
2g @10–500Hz
Shock
IEC60068-2-27:1987, (Test Ea, Unpackaged shock):
Operating - 30g
Non-operating - 50g
Emissions
CISPR 11:
Group 1, Class A (with appropriate enclosure)
ESD Immunity
IEC 61000-4-2:
4kV contact discharges
Radiated RF Immunity
IEC 61000-4-3:
10V/m, with 1kHz sine-wave 80% AM from 30MHz to 1000Mhz
EFT/B Immunity
IEC 61000-4-4:
+2kV at 5kHz on communications ports
Surge Transient Immunity
IEC 61000-4-5:
+2kV line-earth(CM)
on communications ports
Conducted RF Immunity
IEC 61000-4-6:
10Vrms with 1kHz sine-wave 80%AM from 150kHz
to 30MHz
Enclosure Type Rating
None (open style)
Time-of-Day Clock/Calendar
1
Maximum Variations at 60× C:
± 5 min per month
Typical Variations at 20× C:
± 20 s per month
Timing Accuracy:
1 program scan
Available Cartridges
1785-RC Relay Cartridge
Battery
Allen-Bradley 1770-XYC
Memory Modules
• 1785-ME32
• 1785-ME64
• 1785-M100
I/O Modules
Bulletin 1771 I/O, 1794 I/O, 1746 I/O, and 1791 I/O
including 8-, 16-, 32-pt, and intelligent modules
Specifications continued on next page
