12 1738 ArmorPOINT I/O Dual Port EtherNet/IP Adapter
Publication 1738-IN030A-EN-P - July 2013
Network
Activity Off No link established with Port 1 or Port 2.
Flashing green Transmit or receive activity present on Port 1 and/or Port 2 @ 100 Mbps.
Transmit or receive activity present on Port 1 and/or Port 2. One port @
100 Mbps and one port @ 10 Mbps.
Solid green Link established with Port 1 and/or Port 2 @ 100 Mbps.
Link established with Port 1 and Port 2. One port @ 100 Mbps and one
port @ 10 Mbps.
Solid yellow Link established with Port 1 and/or Port 2 @ 10 Mbps.
Flashing yellow Transmit or receive activity present on Port 1 and/or Port 2 @ 10 Mbps.
Network
Status Off Device not initialized. Device does not have an IP address.
Flashing green No CIP connections present. Device has an IP address, but no CIP
connections are established.
Solid green CIP connections present. Device online and has an IP address, and CIP
connections are established.
Flashing red One or more CIP connections in timed-out state. Check for I/O module
failure and controller operation.
Solid red Duplicate IP address detected.
Verify IP address setting and correct, as needed.
Flashing
red/green Module self-test
Link 1 or Link
2 Activity /
Status Off No link established.
Solid green Link established @ 100 Mbps.
Flashing green Transmit or receive activity present on indicated port @ 100 Mbps.
Solid yellow Link established @ 10 Mbps.
Flashing yellow Transmit or receive activity present on indicated port @ 10 Mbps.
POINTBus
Status Off Device is not online.
Device has not completed Dup_MAC_ID test.
Device not powered - check module status indicator.
Flashing green Device is online but has no connections in the established state.
Firmware (NVS) update in progress.
Solid green Adapter online with connections established.
Flashing red Recoverable fault occurred:
• At cycle power, the number of expected modules does not equal the
number of modules present.
• A module is missing.
• Node fault (I/O connection timeout) occurred.
Solid red Unrecoverable fault occurred - POINTbus is off.
System
power Off Not active. Adapter power is off or there is a DC-DC converter problem.
Solid green System power is on. DC-DC converter output is active (5V).
Adapter
power Off Not active. Adapter power is off.
Solid green Power is on. 24V input is present.
Indicator Status for Modules
Indicator State Description
