SLC 5/03, SLC 5/04, and SLC 5/05 Modular Processors 13
Publication 1747-IN009B-EN-P - March 2008
Communication
Communication options for the SLC 5/03, 5/04, and 5/05 processors are as follows:
•
DH485
•
RS-232 protocols (DF1 Full-duplex, DF1 Half-duplex master/slave, DF1
Radio Modem, DH-485, or ASCII)
•
Data Highway Plus (A ControlLogix Gateway is required for the SLC 5/03
and SLC 5/05 processors.)
•
Ethernet TCP/IP (A 1761-NET-ENI interface module is required for the SLC
5/03 and SLC 5/04 processors)
•
ControlNet (via a 1747-KFC15 module)
•
DeviceNet (via a 1761-NET-DNI interface module)
Specifications
Attribute
Value
Power supply loading at 5V dc
500 mA for the SLC 5/03 processor
1.0 A for the SLC 5/04 and 5/05 processors
Power supply loading at 24V dc
175 mA for the SLC 5/03 processor
0 mA for the SLC 5/04 processor
(1)
(1)
SLC 5/04 Processors manufactured prior to April 2002 draw 200 mA at 24V dc. Check your label to verify your processor’s
current draw.
0 mA for the SLC 5/05 processor
Program scan hold-up time after loss of
power
20 ms...3 s (dependent on power supply loading)
Noise immunity
NEMA Standard ICS 2-230
Vibration
Displacement: 0.015 in., peak-to-peak at 5-57 Hz
Acceleration: 2.5 g at 57...2000 Hz
Shock, operating
30 g
Ambient temperature rating, operating
0...60 °C (32...140 °F)
Ambient temperature rating, storage
-40...85 °C (-40...185 °F)
Humidity
5 to 95% without condensation
Agency certification
See
conformity, certificates, and other
certification details.
UL Listed Industrial Control Equipment
C-UL Listed Industrial Control Equipment for use in
Canada
UL Listed Industrial Control Equipment for use in
Class I, Division 2, Hazardous Locations Groups A, B,
C or D
CE compliant for all applicable directives
C-Tick marked for all applicable acts
