Compact TTL Output Module 5
Publication 1769-IN078A-EN-P - May 2006
About the 1769-OG16 Module
Compact I/O is suitable for use in an industrial environment when installed in
accordance with these instructions. Specifically, this equipment is intended for use
in clean, dry environments (Pollution degree 2
(1)
) and to circuits not exceeding
Over Voltage Category II
(2)
(IEC 60664-1)
(3)
.
Module Description
Labels
(1)
Pollution Degree 2 is an environment where, normally, only non-conductive pollution occurs except that occasionally a
temporary conductivity caused by condensation is expected.
(2)
Over Voltage Category II is the load level section of the electrical distribution system. At this level, transient voltages are
controlled and do not exceed the impulse voltage capability of the product’s insulation.
(3)
Pollution Degree 2 and Over Voltage Category II are International Electrotechnical Commission (IEC) designations.
Item Description
1
Bus lever (with locking function)
2a
Upper panel mounting tab
2b
Lower panel mounting tab
3
Module status LED
4
Module door with terminal
identification label
5a
Movable bus connector
with female pins
5b
Stationary bus connector
with male pins
6
Nameplate label
7a
Upper
tongue-and-groove slots
7b
Lower
tongue-and-groove slots
8a
Upper DIN rail latch
8b
Lower DIN rail latch
9
Write-on label (user ID tag)
10
Removable terminal block (RTB)
with finger-safe cover
10a
RTB upper retaining screw
10b
RTB lower retaining screw
10a
10b
4
10
2b
3
2a
1
5a
9
5b
6
7a
7b
8b
7b
8a
7a
1769-OG16
DANGER
Do Not Remove RTB Under Power
Unless Area is Non-Hazardous
Ensure Adjacent
Bus Lever is Unlatched/Latched
Before/After
Removing/Inserting Module
OUT 2
OUT 12
OUT 15
DC
COM
OUT 8
OUT 10
OUT 14
OUT 0
+VDC
OUT 3
OUT 7
OUT 11
OUT 1
OUT 5
OUT 9
OUT 13
OUT 6
OUT 4
D
C
O
U
TP
U
T
3
7
11
15
2
6
10
14
1
5
9
13
0
4
8
12
TTL
0
1
2
3
0
1
2
3
4
5
6
7
DC OUTPUT
2
6
10
14
1
5
9
13
0
4
8
12
15
11
7
3
TTL
DC OUTPUT
2
6
10
14
1
5
9
13
0
4
8
12
15
11
7
3
TTL
