Before you begin, Install the base block – Rockwell Automation 1790D-XXXX DeviceNet Digital Base D-Shell Module CompactBlock LDX I/O User Manual
Page 6
6 DeviceNet Digital Base D-Shell Block CompactBlock LDX I/O
Publication
1790-IN007C-EN-P - May 2006
Before You Begin
Read this section about CompactBlock LDX I/O block requirements.
Current functions of CompactBlock LDX I/O blocks require the
current, modular electronic data sheet (EDS) file for RSNetWorx for
DeviceNet software, version 3.0 or later. These files are available
onl.
EDS files for blocks with matching catalog numbers for both D-Shell
and terminal block versions are the same. On the Web site and in
RSNetWorx for DeviceNet software, find the EDS file for both versions
of the blocks. For example, for the EDS file for 1790D-T8BV8B
blocks, use the EDS file labelled 1790D-8BV8B.
Install the Base Block
To install the base block, follow these steps.
1 . Set the node address on the base block.
2. Mount the base block.
3. Mount the optional expansion blocks.
4. Wire the terminal block.
5. Connect the DeviceNet cable.
