POINT I/O Synchronous Serial Interface Absolute Encoder Module 17
Publication 1734-IN581D-EN-E - January 2014
Input impedance - 3.6 k Ω 4.7 k Ω
Input filter time - 0.5 ms -
*FPV = Field power supply voltage
(1) Time between successive SSI words (Tp). Also called Dwell Time.
(2) Roughly corresponds to the maximum time the SSI sensor can be expected to output a particular position value while in
motion. To use the 1734-SSI module with sensors that have faster position forming times, change the SSI Word Filter
Control parameter from its default value of 5 (max). Changing this parameter from its default value sacrifices electrical
noise environment performance for sensor data conversion speed.
General Specifications
Attribute Value
Terminal base screw torque, max 0.6 Nm (7 lb-in.)
LED indicators All powered from the logic side
Module location 1734-TB, 1734-TBS wiring base assembly
POINTBus current 110 mA @ 5V DC
Power dissipation 0.94 W
Isolation voltage 50V (continuous), Basic Insulation Type
Tested @ 1250V AC for 60 s, field to system
Field power bus supply voltage, min 10V DC @ 450 mA
Field power bus supply voltage, nom 24V DC @ 450 mA
Field power bus supply voltage, max 28.8V DC @ 450 mA
Dimensions, HxWxD 56.0 x 12.0 x 75.5 mm
(2.21 x 0.47 x 2.97 in.)
Conductor category (1) 1 – on signal ports
Wire size 0.34…2.1 mm 2 (22…14 AWG) solid or stranded copper wire
rated @ 75 °C (167 °F), or greater, 1.2 mm (3/64 in.)
insulation max
Wire type Copper
Shielded on encoder port
Weight 0.032 kg (0.07 lb)
Keyswitch position 2
POINT I/O Synchronous Serial Interface Absolute Encoder Module –
1734-SSI, Series C
Attribute Value
