Allen-Bradley Power Supply Modules 5
Place the Power Supply in a Chassis
You can place these power-supply modules into any I/O module slot in any
current chassis (1771-A1B, -A2B, -A3B, -A3B1, -A4B, -PSC).
However, to place these power-supply modules into a superseded I/O
chassis (1771-A1, -A2, -A4), you must follow the restrictions in the
following table.
The power supply is a modular component of the 1771 I/O system,
requiring a properly installed system chassis. Refer to publication
1771-IN075 for detailed information on acceptable chassis and proper
installation and grounding requirements. Limit the adjacent slot power
dissipation to a maximum of 10W.
WARNING
7XUQ RII DOO SRZHU VXSSO\ PRGXOHV EHIRUH UHPRYLQJ
PRGXOHV IURP RU LQVHUWLQJ PRGXOHV LQWR D FKDVVLV )DLOXUH
WR REVHUYH WKLV ZDUQLQJ FRXOG DOWHU SURFHVVRU PHPRU\
GDPDJH PRGXOH FLUFXLWU\ DQG FDXVH XQLQWHQGHG RSHUDWLRQ
ZKLFK FRXOG SRVVLEO\ FDXVH LQMXU\ WR SHUVRQQHO
WARNING
,Q \RX LQVHUW RU UHPRYH WKH PRGXOH ZKLOH EDFNSODQH SRZHU
LV RQ RU LI \RX FRQQHFW RU GLVFRQQHFW WKH ILHOG ZLULQJ
FRQQHFWRU ZLWK ILHOG SRZHU DSSOLHG DQ HOHFWULFDO DUF FDQ
RFFXU 7KLV FRXOG FDXVH DQ H[SORVLRQ LQ KD]DUGRXV ORFDWLRQ
LQVWDOODWLRQV %H VXUH WKDW SRZHU LV UHPRYHG RU WKH DUHD LV
QRQKD]DUGRXV EHIRUH SURFHHGLQJ
Adapter or
in-chassis
processor
I/O Chassis 1st Power Supply
1
2nd Power Supply
1
Without an integral
power supply 1771-A4 I/O slot 0 I/O slot 10
1771-A2 I/O slot 0 I/O slot 4
1771-A1 I/O slot 0 not applicable
With an integral power
supply 1771-A4 not applicable I/O slot 8
1771-A2 not applicable I/O slot 3
1
I/O module slots are numbered 0 thru 15, left to right.
