8. Installation Mode
8. INSTALLATION MODE
Overview
• Start up of the Installation mode
• Input Slots
• 800 peripheral
• Source Switching
• No Signal
• Contrast Enhancement
• Convergence
• Configuration
• Lens Adjustment
• Quick Access Keys
• OSD
• Internal Patterns
8.1 Start up of the Installation mode
Start up
1. Push the cursor key ↑ or ↓ to highlight Installation. (menu 8-1)
2. Press ENTER.
The Installation mode menu will be displayed. (menu 8-2)
ADJUSTMENT MODE
Select a path from below :
RANDOM ACCESS
INSTALLATION
SERVICE
Select with ↑ or ↓
then
to return
Menu 8-1
INSTALLATION
INPUT SLOTS
800 PERIPHERAL
SOURCE SWITCHING
NO SIGNAL
CONTRAST ENHANCEMENT
CONVERGENCE
CONFIGURATION
LENS
QUICK ACCESS KEYS
OSD
INTERNAL PATTERNS
Select with ↑ or ↓
then
to return
Menu 8-2
8.2 Input Slots
What can be done ?
The input configuration of the variable inputs is shown in the Input slots menu.
