7. Random Access Adjustment Mode
7.4 Geometry
Overview
•
•
•
•
•
•
•
•
7.4.1
Introduction
Introduction
An adjustment can be done as follow :
1.
Using the cursor key to adjust
2.
Entering the value with the digit keys. Therefore, press ENTER to select the indicated value and enter the desired value with
the digit keys. Press ENTER to confirm the entered value.
7.4.2
Geometry start up
Start up
1. Push the cursor key ↑ or ↓ to highlight Geometry. (menu 7-40)
2. Press ENTER to select.
The geometry menu will be displayed. (menu 7-41)
ADJUSTMENT MODE
Select a path from below :
RANDOM ACCESS
INSTALLATION
SERVICE
Select with
↑
or
↓
then
Menu 7-40
GEOMETRY
SHIFT
SIZE
SIDE KEYSTONE
BLANKING
ASPECT RATIO [4:3]
OPTIONS
Select with
↑
or
↓
then
Menu 7-41
7.4.3
Shift
What can be done ?
The image can be shifted in a horizontal or vertical direction.
R5976563 BARCOR10 SLM 20/10/2004
69
