2. Packaging and Dimensions
2.3 Lamp Packaging
Way of packaging
As it is not allowed to transport the projector with the lamp mounted inside the projector, this lamp is packed in a separate carton box.
Save this carton box , it can be used to repack the lamp when you ever have to transport your projector.
2.4 Lens Packaging
Way of Packaging
Lenses are supplied as an individual item.
They are packed in a carton.
2.5 Projector Case
Dimensions
The dimensions are given in mm
25.4mm = 1 inch
372,
7
466
83
373
0
456
64,5
520,5
162
38
418
118
64,
5
AIR IN
AIR OUT
IR-receiver
FRONT VIEW
Image 2-2
Front view dimensions
4
R5976563 BARCOR10 SLM 20/10/2004
