Preface

Publication 1772Ć10.1 - March 1996

Preface

This quick start is designed to help you quickly install and connect a
basic PLC-2 family programmable controller system. Use this guide
if you are knowledgeable about PLC-2 family products but may not
have used one or more of the products for a period of time. The
information we provide is geared to “jog your memory.”

step 1

For more information, see the PLCĆ2 Programmable Controllers

Assembly and Installation Manual, publication 1772Ć6.6.2.

For more
information...

Configure and connect a Programming Terminal

(page 6Ć1)

Configure I/O chassis

(page 1Ć1)
Ground I/O chassis

(page 1Ć2)

Install memory module

(page 2Ć1)

Install and connect I/O adapter

(page 3Ć1)
Install and connect I/O modules

(page 3Ć2)

Install power supply

(page 4Ć1)

Install and connect remote I/O scanner and adapter

(page 5Ć1)

step

step
step
step

a
b

PLC

Install I/O chassis

Install I/O

Using this Quick Start

What You Need to Do
