Configuration Data File
The manipulation of the bits from this file is normally done with
programming software (e.g. RSLogix 500, RSNetworx for DeviceNet, etc.)
during initial configuration of the system. In that case, graphical screens are
provided by the programmer to simplify configuration. However, some
systems, like the 1769-ADN DeviceNet Adapter, also allow the bits to be
altered as part of the control program, using communication rungs. In that
case, it is necessary to understand the bit arrangement. Refer to the
Compact™ Analog I/O User Manual, publication number
1769-UM002A-EN-P for additional details.
Words 0 to 3 of the configuration file allow you to change the parameters
of each channel independently. For example, word 0 corresponds to
channel 0.
Define
To Select
Make these bit settings
15
14
13
12
11
10
9
8
4-7
3
2
1
0
Input Filter
Selection/
-3 dB
Frequency
60 Hz/15.7 Hz
Not
Us
ed
0
0
0
0
50 Hz/13.1 Hz
0
0
0
1
Not Used
0
0
1
0
250 Hz/65.5 Hz
0
0
1
1
500 Hz/131Hz
0
1
0
0
Spare
(1)
(1) An attempt to write any non-valid (spare) bit configuration into any selection field results in a module
configuration error.
Input Type/
Range
-10 to +10V dc
0
0
0
0
0 to 5V dc
0
0
0
1
0 to 10V dc
0
0
1
0
4 to 20 mA
0
0
1
1
1 to 5V dc
0
1
0
0
0 to 20 mA
0
1
0
1
Spare
Input Data
Format
Raw/Proportional
Data
0
0
0
Engineering Units
0
0
1
Scaled-for-PID
0
1
0
Percent Range
0
1
1
Spare
Enable
Channel
Enabled
1
Disabled
0
