Supply voltage
Power supply: 19.2...31.2V DC, 400 mA
DeviceNet power: 24V DC, 90 mA, Class 2
Flexbus output: 5V DC, 640 mA
Input voltage
rating
24V DC nom
19.2V to 31.2 V DC (includes 5% AC ripple)
Current draw
400 mA maximum; 300 mA at 24V DC
Communication
rate
125 KB
250 KB
500 KB
Indicators
Power - on/off
ModNet status - red/green
I/O status - red/green
Flexbus output
current
640 mA max. @ 5V DC
Isolation
voltage
50V (continuous), Basic Insulation Type
Type tested at 1930V DC for 60 s, power to Flexbus, power to
DeviceNet, and DeviceNet to Flexbus
Power
dissipation
7.6W maximum @ 19.2V DC
Thermal
dissipation
26 BTU/hr @ 19.2V DC
DeviceNet
power
requirements
24V DC (
±
4%) at 90 mA max
Dimensions
(HxWxD)
87 x 68 x 69 mm (3.4 x 2.7 x 2.7 in)
Weight
195.5 g (6.9 oz)
Enclosure type
rating
None (open-style)
Wire size
Power connections:
0.33... 3.3 mm² (22...12 AWG) solid or stranded copper wire
rated at 75 °C (167 °F ) or greater 1.2 mm (3/64 in.) insulation
max
Wiring
category
(1)
1 - on power ports
2 - on communications ports
Terminal screw
torque
0.8 Nm (7 lb-in)
North American
temp code
T4
IEC temp code
T4
(1)
Use this Conductor Category information for planning conductor routing. Refer to Industrial
Automation Wiring and Grounding Guidelines, publication
1770-4.1.
Environmental
Attribute
Value
Operating
temperature
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20…70 °C (-4…158 °F)
Surrounding
air
temperature,
max
70 °C (158 °F)
Non-operating
temperature
IEC 60068-2-1 (Test Ab, Unpackaged Non-operating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Non-operating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Non-operating Thermal
Shock):
-40…85 °C (-40…185 °F)
Relative
humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):
5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc, Operating):
5 g @ 10…500 Hz
General
Operating
shock
IEC 60068-2-27 (Test Ea, Unpackaged Shock):
30 g
Non-operating
shock
IEC 60068-2-27 (Test Ea, Unpackaged Shock):
50 g
Emissions
CISPR 11:
Group 1, Class A (with appropriate enclosure)
ESD immunity
IEC 61000-4-2:
6 kV contact discharges
8 kV air discharges
Radiated RF
immunity
IEC 61000-4-3:
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM at 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM at 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
EFT/B
immunity
IEC 61000-4-4:
±4 kV at 5 kHz on power ports
±4 kV at 5 kHz on communications ports
Surge
transient
immunity
IEC 61000-4-5:
±1 kV line-line(DM) and ±2 kV line-earth(CM) on power ports
±2 kV line-earth(CM) on communications ports
Conducted RF
immunity
IEC 61000-4-6:
10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz
Certifications (when product is marked)
(1)
(1)
See the Product Certification link at
http://www.ab.com
for Declaration of Conformity, Certificates, and
other certification details.
Attribute
Value
c-UL-us
UL Listed Industrial Control Equipment, certified for US and
Canada. See UL File E65584.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous
Locations, certified for U.S. and Canada. See UL File E194810.
CE
European Union 2004/108/EC EMC Directive, compliant with:
EN 61326-1; Meas./Control/Lab., Industrial Requirements
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
C-Tick
Australian Radiocommunications Act, compliant with:
AS/NZS CISPR 11; Industrial Emissions
Ex
European Union 94/9/EC ATEX Directive, compliant with:
EN 60079-15; Potentially Explosive Atmospheres, Protection "n"
EN 60079-0; General Requirements
II 3 G Ex nA IIC T4 X
ODVA
ODVA conformance tested to DeviceNet specifications
Environmental
