12 DeviceNet ArmorBlock™ Network Powered 16-input Module
Publication 1732D-IN007B-EN-E - November 2011
Specifications
General Specifications
Attribute Value
Number of inputs 16
Input type 61131-2 Type 3 compatible
Off-state input voltage, max 5V DC
On-state input voltage, min 11V DC
On-state input voltage, nom 24V DC
On-state input voltage, max 25V DC
Sensor source voltage, min 11V DC
Sensor source voltage, max 25V DC
Off-state input current, max 1.5 mA @ 5V DC
On-state input current, max 5 mA @ 25V DC
Input delay time (1) 
Off to On 
On to Off
0…16,000 s
DeviceNet power
voltage range 11…25V DC
Sensor source current
per module, max 500 mA
DeviceNet current 75 mA plus sum of sensor currents
Indicators 1 green/red – module status 
1 green/red – network status 
16 yellow – input status
Isolation voltage 50V (continuous), Basic Insulation Type, inputs to network 
No isolation between individual inputs 
Type tested @ 707V DC for 60 s
Communication rate 125 Kbps @ 500 m (1640 ft) for thick cable, flat media length 375 m (1230 ft) 
250 Kbps @ 200 m (600 ft) for thick cable, flat media length 150 m (492 ft) 
500 Kbps @ 100 m (330 ft) for thick cable, flat media length 75 m (246 ft)
Dimensions (HxWxD),
approx. 179 x 65 x 43.25 mm 
(7.05 x 2.56 x 1.70 in)
Enclosure type rating Meets IP65/66/67/69K (when marked), and NEMA 4X/6P with receptacle
dust caps or cable termination
Wiring category (2)(3) 1 – on signal ports 
2 – on communication ports
Weight, approx. 0.392 kg (0.864 lb)
