Compact 32-point Solid-state 24V dc Source Output Module 19
Publication 1769-IN080A-EN-P - August 2006
Program to Fault Enable Bit (PFE)
Word 0, bit 0, allows the selection of which data
value, the program or fault value, to apply to the
output if a system in Program mode undergoes a
system fault, resulting a change to Fault mode.
Module Default Condition
The module’s default condition is all zeros, programming the conditions shown.
Program Conditions
Word or Bit Affected Condition Applied
Word 0, Bit 0 Program-to-fault Enable Program value
Word 1 Program state User-defined safe state
Word 2 Program value Off
Word 3 Fault state User-defined safe state
Word 4 Fault value Off
Value Applied Bit Setting
Program 0
Fault 1
