Compact 32-point Solid-state 24V dc Source Output Module 17
Publication 1769-IN080A-EN-P - August 2006
r = read
Configuration File
The read/writable configuration data file allows the setup of the hold last state and
user-defined safe-state conditions.
Manipulate these bits with programming software, such as, RSLogix 500 or
RSNetWorx for DeviceNet, during initial configuration of the system. In that case,
graphical screens are provided via the programmer to simplify configuration.
However, some systems, such as, 1769-ADN DeviceNet Adapter, also allow the bits
to be altered as part of the control program using communication rungs. In that
case, it is necessary to understand the bit arrangement.
Output Module’s Input Data File
Wo
rd
Bit Position
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
0
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
1
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
IMPORTANT
The output module’s input data file reflects the output data echo of the
module, not necessarily the electrical state of the output terminals. It does not
reflect shorted or open outputs.
It is important to use this input word if the controller adapter supports the
Program mode or Fault mode function, and if it is configured to use them.
Configuration File
Wo
rd
Bit Position
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
PFE
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
2
Program State for Output Array Word 0
3
Program State for Output Array Word 1
4
Program Value for Output Array Word 0
5
Program Value for Output Array Word 1
6
Fault State for Output Array Word 0
7
Fault State for Output Array Word 1
8
Fault Value for Output Array Word 0
