IV. Conversion Module Specifications
(Operating specifications are when installedin the Conversion System base / cover-plate assembly)
Specification
Dimensions
Storage Temperature -40 to +85°C (-40 to +185°F)
Operating Temperature 0 to 60°C (32 to 140°F)
Operating Humidity 5 to 95% at 60°C (non-condensing)
Shock
Non
-
operating
Operating
50g
30g
Operating Vibration 2g at 10 to 500Hz (Agrees with 1756 I/O module specifications)
Maximum Operating Voltage 240 Vac at 47 to 63Hz
Max. Module Operating Current
Per Point:
Per Module:
2 Amps
4 Amps
Agency Certifications UL Classified: Under UL File Number E113724
CSA
CE: compliant for all applicable directives
Pollution Degree 2
Environmental Rating IP20
Refer to the Wiring Diagram(s) for
current limits for a specific configuration. NOTICE
Value
Approximate Shipping Weight
11.81 in. (height) x 4.38 in. (depth) x 1.5 in. (width)
300 mm. (height) x 111.25 mm (depth) x 38.1 mm (width)
265.4 g (0.58 lbs) (includes carton)
PN-114285
DIR 10000060096 (Version 01)
Publication 1492-IN044B-EN-E
III. Compatibility
Table 2: Bulletin 1771 to 1756 Conversion Modules and Cables
1771
Digital I/O Module
1756
Digital I/O Module
1492
Conversion Module
1492
Cable
1771-OAN 1756-OA16 (Qty 2) 1492-CM1771-LD013 1492-CONCAB005S3
1771-OVN 1756-OV16E (Qty 2) 1492-CM1771-LD013 1492-CONCAB005S3
1771-OWNA 1756-OW16I (Qty 2) 1492-CM1771-LD013 1492-CONCAB005S4
Foot Notes:
To understand any issues concerning I/O module compatibility, refer to the Installation Manuals for the specific 1771
and 1756 I/O modules involved. The (2) 1756 modules must be located directly next to each other in the 1756
chassis.
The 3 numbers indicate the cable length of the 1492 Cable. Recommended cable length of 0.5M is shown.
Alternative cable lengths are as follows:
1.0M = 1492-CONCAB010S3
1.0M = 1492-CONCAB010S4
