Publication 1405-IN001B-EN-P - October 2003
Bulletin 1405 (M610) Operating Instructions 7
Temperature Coefficient < 0.01% / K
Input Impedance (Voltage Inputs) 2 Mohm (Lx to N)
Input Impedance (Current Inputs) 0.01 ohm at 5A
Overload Rating Voltage 110% (continuous)
Current 200% (continuous)
Frequency Range 47 to 63 Hz
Power Consumption 3W typical
Operating Temperature +5°C to +50°C (+41°F to +122°F)
Storage Temperature -20°C to +70°C (-4°F to +158°F)
Protection Class Enclosure IP 20 (IP 65 with optional protective
hood
(1)
)
Terminals IP 00
Weight Approximately 0.3 kg
Front Dimensions 96 mm x 96 mm (3.78 in x 3.78 in)
Breakdown Rating Per DIN 41700
Depth 65 mm (2.56 in)
Panel Mounting Spring Clamps
Agency Certifications UL, CE
(1) The optional hood, catalog number 1405-PRO, can be ordered separately. Contact your Rockwell Automation
distributor for additional information.
Table 3 General Parameters
Parameter Value
Table 4 Measurement Accuracy and Range
Parameter Percent of Reading Nominal Value Operating Range Maximum Limit
Volts ±1% 240V rms 10V rms to 347V rms L-N
or 17V rms to 600V rms
L-L 400V rms L-N or 690V
rms L-L
Current ±1% 5 Amps 0.1 Amps to 6 Amps 10 Amps
