V. Wiring Diagrams
1771-WN Swing Arm
From 1771-IAN
There are several key application considerations and system specifications (bottom of drawing) when
using these components (conversion module, cable and input module). Read and understand these
considerations before installation.
WARNING
Conversion: 1771-IAN to 1756-IA32
Conversion Module Installation and Application Considerations
The input delay times for the 1771-IAN module versus 1756-IA32 module are as follows:
1771-IAN
1756-IA32
a) Off-to-On Delay
10ms (+/-7ms)
10ms max (plus selectable filter)
b) On-to-Off Delay
20ms (+/-15ms)
8ms max (plus selectable filter)
The 1771-IAN has 4 groups(allowing 4 seperate power supplies) and the 1756-IA32 has 2 groups.
This module/cable combination ties Groups 0 & 1 from the 1771-IAN to Group 0 on the 1756-IA32 and it ties Groups 2 & 3
from the 1771-IAN to Group 1 on the 1756-IA32. Field wiring modification must be made to accommodate this if multiple
supplies were used. If 4 supplies were used, 2 must be removed.
Refer to your 1771-IAN and 1756-IA32 Installation Manual wiring schematics and diagrams for more details.
