28
Bul. 937C Transmitter Supply Converter Installation Instructions
Fault current
The following table shows the current output in the event of a fault, depending on the characteristic.
Start value and End value
Please note when entering Start value and End value:
• Both values are to be entered in the units, which were selected under Units.
• Values between 0 mA and 20 mA can be entered, or between the values of these limits converted
into the selected units, using the parameters Zero point and Conversion factor.
The difference between End value and Start value must be at least 1 % of the End value (preset
automatically by the transmitter supply converter).
Setting 0 mA ... 20 mA 4 mA ... 20 mA NE43 4 mA ... 20 mA
Up/Down 21.5 mA 21.5 mA 22 mA
with short-circuit with short-circuit with short-circuit
(not distinguishable from
End value overrange)
0 mA 2.0 mA 0 mA
with lead breakage with lead breakage
(not distinguishable from
Start value measurement)
with lead breakage
(not distinguishable from
Start value underrange)
Hold Last measured value before the fault
Max 21.5 mA 21.5 mA 22 mA
(not distinguishable from
End value overrange)
Min 2.0 mA 0 mA
(not distinguishable from
Start value measurement)
0 mA
(not distinguishable from
Start value underrange)
