Air Flow Switch 5
Publication 1414-IN003A-EN-P - October 2005
Life 100,000 cycles/min. at 5psi
max pressure each cycle
and at max electrical load. 100,000 cycles/min. at
5psi max pressure each
cycle and at max
electrical load. 600 cycles/min. at 5psi
max pressure each cycle
and at max electrical
load.
Electrical Rating 300 va pilot duty at
115…277vac, 10 amp,
non-inductive, 277 vac,
60Hz. 300 va pilot duty at
115…277vac, 10 amp,
non-inductive, 277 vac,
60Hz. 300 va pilot duty at
115…277vac, 10 amp,
non-inductive, 277 vac,
60Hz.
Contact Arrangement SPDT SPDT SPDT
Electrical Connections Screw top terminals with
cup washers Screw top terminals with
cup washers Screw top terminals with
cup washers
Sample Line
Connections Ferrule and nut
compression type
connectors that accept .25”
OD rigid tubing. Ferrule and nut
compression type
connectors that accept
.25” OD rigid tubing. Ferrule and nut
compression type
connectors that accept
.25” OD rigid tubing.
Automatic/Manual
Reset Automatic Automatic Manual
Air Flow Switch Specifications
Specification 1414-CPN10APWAB 1414-CPN10APQAB 1414-CPM10APWAB
