Rockwell Automation 1492-XIMTRxxx_RXIMTRxxx 16 and 32 Point Relay Interface Modules - Manual (Page 5)

PN-91272
DIR 10000083677 (Version 02)
Publication 1492-IN052C-MU-E
(5)
Relay Contact Rating
Spécification du Contact à Relais
700-TBR24
Relaiskontakt-Nennwerte
Classificazione Contatti di Relay
Capacidad Nominal del Contacto de Relé
Electrical Ratings
ORDINARY LOCATIONS
Electrical Ratings
HAZARDOUS LOCATION
Contacts Inductive VAC
Inductive VDC
Minimum Permissible Contact Ratings:
12V, 6mA (72mW) silver contacts (700-TBR24)
8V, 2.5mA (50mW) gold contacts (700-TBR24X)
General Purpose VAC
Rated Insulation Voltage ( Ui ) 250V IEC, 300V UL/CSA
1-Pole, 1 CO, SPDT 3A, Ta 0°C - 60°C
1-Pole, 1 CO, SPDT 4A, Ta 0°C - 50°C Rated Thermal Current ( I th )
120 V B300 Pilot Duty, 3A , Ta 0°C - 60° C
240 V B300 Pilot Duty, 1.5A , Ta 0°C - 60°C
125 V
250 V R300 Pilot Duty, 0.22A , Ta 0°C - 60°C
R300 Pilot Duty, 0.11A , Ta 0°C - 60°C
Replacement Relays
·
24VDC Control (Coil) Voltage: 700-TBR24 or 700-TBR24X
250V 3A , Ta 0°C - 60° C
250V 4A , Ta 0°C - 50°C
Resistive VDC 24V 4A, Ta 0°C - 40°C
Listed Ind. Cont. Eq. A191
Contacts Inductive VAC
Inductive VDC
General Purpose VAC
Rated Insulation Voltage ( Ui ) 250V IEC, 300V UL/CSA
1-Pole, 1 CO, SPDT 2A, Ta 0°C - 50°C
1-Pole, 1 CO, SPDT 3A, Ta 0°C - 40°C Rated Thermal Current ( I th )
120 V C300 Pilot Duty, 1.5A , Ta 0°C - 50°C
240 V C300 Pilot Duty, 0.75A , Ta 0°C - 50°C
125 V
250 V R300 Pilot Duty, 0.22A , Ta 0°C - 50°C
R300 Pilot Duty, 0.11A , Ta 0°C - 50°C
250V 2A , Ta 0°C - 50°C
250V 3A , Ta 0°C - 40°C
Resistive VDC 24V 3A, Ta 0°C - 40°C
Ind. Cont. Eq. for Haz. Loc.
Listed A196
Class I, Div.2, Groups A,B,C,D
Class I, Zn2, Groups IIC
Minimum Permissible Contact Ratings:
12V, 6mA (72mW) silver contacts (700-TBR24)
8V, 2.5mA (50mW) gold contacts (700-TBR24X)
WARNING: Explosion Hazard.
Do not disconnect equipment unless power has been switched off or the area is known to be non-hazardous.
Exposure to some chemicals may degrade the sealing properties of materials used in the relay.
Relay - epoxy resin, Three Bond International, TB2206C
Relay cover, Ticona, Celenax 3216
Relay base, Evonik Degussa GMBH, Vestodur X7212
Periodically inspect the relay for any degradation of properties and replace if degradation is found.
This equipment is suitable for use in Class I, Division 2, Groups A, B, C and D or non-hazardous locations only. Substitution of relay may impair suitability
for Class I, Division 2. Power, input and output (I/O) wiring must be in accordance with Class I, Div. 2 wiring methods - Article 501 - 10 (B) (1) of the
National Electrical Code.
