14
F-Series Motor Installation Instructions
Publication 1398-IN516B-EN-P — February 2002
Cables and Connector Kits
Factory manufactured cables are available in standard cable lengths.
Contact your nearest Allen-Bradley sales office or refer to your drive’s
installation manual for a complete listing of available cables.
If you choose to build your own cables, the following connector kits are
available for F-Series motors.
Shaft Seal Kits
F-Series motors equipped with a shaft seal will have an IP65
environmental rating. The following shaft seal kits are available for
F-Series motors.
Catalog Number
Description
2090-FPC-S4000
Straight Power Connector Kit Compatible with 2 and 3 kW Drives
2090-FPC-R4000
Right-Angle Power Connector Kit Compatible with 2 and 3 kW Drives
2090-FPC-S6000
Straight Power Connector Kit Compatible with 7.5 kW Drives
2090-FPC-R6000
Right-Angle Power Connector Kit Compatible with 7.5 kW Drives
2090-FFC-S
Straight Feedback Connector Kit Compatible with All Drives
2090-FBC-S
Straight Brake Connector Kit Compatible with All Drives
2090-FFC-R
Right-Angle Feedback Connector Kit Compatible with All Drives
2090-FBC-R
Right-Angle Brake Connector Kit Compatible with All Drives
Catalog Number
Description
0041-5060
Shaft Seal Kit for F-4000 Series Motors
0041-5061
Shaft Seal Kit for F-6000 Series Motors
