5-2
Commissioning
Pre-start-up Inspection (cont.)
• For future reference, record component data on the table below:
Table 5.A
Component Specifications
Fifth Filter
Seventh Filter
Eleventh Filter
Capacitor kVAR
(3) @
(3) @
(3) @
(3) @
Capacitor Farads
(3) @
(3) @
(3) @
(3) @
Reactor Amps
Reactor mH
Reactor Tap Connection
CT Ratio
(3) @
(3) @
(3) @
(3) @
O/L Elements
SMP-3 Setting (FLC)
Settings
The SMP-3 relay(s) are factory set to allow detection of a blown capacitor fuse
(phase loss detection). No adjustment should be required on the SMP-3 relay(s).
The overload elements are factory selected and installed to provide proper
overload protection. No adjustment should be required on the heater elements.
The reactor(s) are factory set on the nominal inductance tap. The reactor(s)
have ±5% taps to allow increasing or decreasing the inductance and thus
changing the tuned frequency of the filter.
In general, Rockwell Automation should be consulted when considering a
change to a reactor tap setting, SMP-3 setting or 592 heater elements.
