The following is an explanation of the catalog numbering system for
1336 IMPACT Common Bus AC Drives and options. The catalog
number is coded to identify the drive power rating and can be found
on the drive shipping carton and nameplate.
Catalog Number Explanation
➊ Not available.
1336E
– Use Number for
Specific Constant
Torque Drive
– EN – L6 – HA1 – GM1
BULLETIN
NO.
RATING-
ENCLOSURE
(MUST BE
SPECIFIED)
LANGUAGE
MODULE
(MUST BE
SPECIFIED)
L-Option
(OPTIONAL)
HUMAN
INTERFACE
(OPTIONAL)
COMMUNICATION
CARD
(OPTIONAL)
Drive Rating
Enclosures
Open
IP00
No Enclosure
NEMA Type 1
IP20
General Purpose
NEMA Type 12
IP54
Industrial Use
Frame
Designation
Output
Amps
Nominal
HP
Code Code Code
513 – 620V DC Input
G 406.4
459.2
505.1
570.2
599.2
673.4 300
350
400
450
500
600 R300-AN
R350-AN
R400-AN
R450-AN
R500-AN
R600-AN R300-AA
R350-AA
R400-AA
R450-AN
R500-AN
R600-AN R300C-AJ
R350C-AJ
R400C-AJ
Not available
Not available
Not available
675 – 800V DC Input
G 298.0
353.6
406.4 ➊
459.2
505.1
599.2
673.4
300
350
400
450
500
600
650 W300-AN
W350-AN
W400-AN
W450-AN
W500-AN
W600-AN
W650-AN W300-AA
W350-AA
W400-AA
W450-AA
W500A-AA
W600A-AA
W650A-AA W300C-AJ
W350C-AJ
W400C-AJ
Not available
Not available
Not available
Not available
513 – 620V DC Input
H 850.0
983.0 700
800 Not available
Not available R700C-AA
R800C-AA Not available
Not available
775 V DC Input
H 770.0
800.0 700
800 Not available
Not available 12W700C-AA
12W800C-AA Not available
Not available
