Rockwell Automation 1492-CM800-LD004 Field Wire Conv. Module for Modicon B806-032 to 1756-OA16 - Manual (Page 3)

(3) 10000021863 (Version 00)
V. 1492-CM800-LD004 Conversion Module Specifications
(Operating specifications are when installed in the Conversion System base / cover-plate assembly)
Specification Value
Dimensions 288.9 mm (height) x 139.7 mm (depth) x 44.5 mm (width)
11.37 in. (height) x 5.5 in. (depth) x 1.75 in. (width)
Approximate Shipping Weight 300g (0.66 lbs) (includes carton)
Storage Temperature -40 to +85°C (-40 to +185°F)
Operating Temperature 0 to 55°C (32 to 131°F)
Operating Humidity 5 to 95% at 55°C (non-condensing)
Shock
Non-operating
Operating
50g
30g
Operating Vibration 2g @ 10-500Hz
Maximum Operating Voltage 125 Vac at 47 to 63 Hz
Max. Module Operating Current
Per Point:
Per Module: 2 Amps (1492-CABLE connection pins are limited to 2A per pin)
12 Amps
Agency Certifications
UL Classified: Under UL File Number E113724
CSA
CE: compliant for all applicable directives
Pollution Degree 2
Environmental Rating IP20
Conversion Module Installation and Application Considerations

This configuration uses two (2) 1756-OA16 output modules to replace a single B806-032 output module. This may require the use
of a larger 1756 I/O Chassis. Ensure there is sufficient panel space to allow for this possibility.
 The B806-032 module output current limits versus 1756-OA16 limits are as follows:
B806-032 1756-OA16 w/ 1492-CABLE003X
a) Current/Point 1A 0.5A
b) Current/Group 8A 2A
c) Current/Module 16A (32 pts) 4A (16 pts)
d) Surge Current/Pt 15A for 1 cycle 5A for 43ms
 The B806-032 module did NOT provide fusing. The 1756-OA16 provides a single fuse per group.
 The 1492-CABLE003X current is limited to 2A per pin.

Refer to your B806-032 and 1756-OA Installation Manual wiring schematics and diagrams for more details. Ensure 1756 output
module ratings are not exceeded. [Reference Doc: 41170-753 (Version 03)]
Refer to the Wiring Diagram(s) for
current limits for a specific configuration. NOTICE
1492-CM800-LD004 Conversion Module
De-energize and lockout any and all power to all I/O field devices connected to the Modicon 800 I/O
housing, and the power to the 800 I/O housing itself. Ensure all power is de-energized and locked out to
any device in the control cabinet where the conversion is to be performed. Ensure work is performed by
qualified personnel. WARNING
 Refer to conversion module Specifications Section: Maximum Operating Voltage
