1204 Reflected Wave Reduction Device 3
Dimensions and Weights Dimensions, weights and conduit entry locations for the “Stack” and
“Book” style units are provided below.
B
A C
G
H
C'
J
Conduit Entry – 2 Places
22.5 (0.88) Dia.
Dimensions are in millimeters and (inches)
D F
E
J'
Catalog
Number
1204-RWR2-09-B
1204-RWR2-09-C
"Book" Style – B Frame Only
"Stack" Style
A
180.0
(7.09)
220.0
(8.66)
B
205.0
(8.07)
205.0
(8.07)
C
72.9
(2.87)
72.9
(2.87)
C'
76.5
(3.01)
76.5
(3.01)
G
40.0
(1.57)
40.0
(1.57)
H
85.0
(3.35)
125.0
(4.92)
J
45
(1.77)
45
(1.77)
D
180.0
(7.09)
NA
E
248.2
(9.77)
NA
F
60.0
(2.35)
NA
J'
47.5
(1.87)
NA
Approx.
Weights
3.47 kg
(7.66 lb.)
3.80 kg
(8.33 lb.)
Conduit Entry – 2 Places
22.5 (0.88) Dia.
