10

N

OTE

:

S

ETTINGS ARE MADE THROUGH SUPPLIED

P

OWER

C

HUTE SOFTWARE

,

OPTIONAL

N

ETWORK

M

ANAGEMENT CARDS

,

OR

T

ERMINAL

M

ODE

.

F

UNCTION

F

ACTORY

D

EFAULT

U

SER

S

ELEC TABLE

C

HOICES

D

ESCRIPTION

Low Bypass Point

-30% of output
voltage setting

-15%, -20%, -25%, -30%

Minimum voltage that the UPS
will pass to connected
equipment during internal
bypass operation.

Output Voltage

3 kVA 120 V
models:
120 VAC

208/230 V models:
230 VAC

3 kVA 120 V models:
120 VAC


208/230 V models:
200, 208, 220, 230,
240 VAC

Allows the user to select the on
battery output voltage.

Output Frequency

Automatic

50 ± 3 Hz or
60 ± 3 Hz

50 ± 3 Hz
50 ± 0.1 Hz
60 ± 3 Hz
60 ± 0.1 Hz

Sets the allowable UPS output
frequency. Whenever possible,
the output frequency tracks the
input frequency.

Number of
Battery Packs

1

Number of Connected
Internal Battery Packs,
(two modules per pack)

Defines the number of
connected battery packs for
proper run time prediction.

Connecting the EPO (Emergency Power Off) Option

The output power can be disabled in an emergency by closing a switch connected to the EPO.

Adhere to National and local electrical codes when wiring the EPO.

Rockwell Automation recommends Allen-Bradley Catalog Number 800F Emergency Stop Operator
as the interface to the EPO to connector.

The EPO switch is internally powered by the UPS for use with non-powered switch circuit breakers.

The EPO circuit is considered a Class 2 circuit, (UL, CSA standards) and a SELV circuit (IEC
standard).

Both Class 2 and SELV circuits must be isolated from all primary circuitry. Do not connect any
circuit to the EPO terminal block unless it can be confirmed that the circuit is Class 2 or SELV.

If circuit standard cannot be confirmed, use a contact closure switch.
