User Configurable Items
The UPS settings are adjusted through PowerChute software.
Storage
Store the UPS covered in a cool, dry location with the battery module(s) fully charged.
At 5° to 86° F (–15° to 30° C), charge the UPS battery module every six months.
At 86° to 113° F (30° to 45° C), charge the UPS battery module every three months.
Installing/Replacing the Battery Module
This UPS has an easy-to-replace, hot-swappable battery module. The corresponding replacement battery module is 1609-500SBAT.
Replacement is a safe procedure, isolated from electrical hazards. You may leave the UPS and connected equipment on during the
replacement procedure.
For instruction, see applicable steps in Battery Connection.
Troubleshooting
Access the troubleshooting guide for this UPS through PowerChute software.
Function Factory Default User Selectable Choices Description
Automatic
Self-Test Every 14 days (336
hours) • Every 7 days
(168 hours)
• On start up only
• No self-test
Set the interval at which the UPS will execute a self-test.
UPS ID UPS_IDEN Up to eight characters
(alphanumeric) Uniquely identify the UPS (i.e. server name or location) for
network management purposes.
Date of Last Battery
Replacement Manufacture Date mm/dd/yy Reset this date when you replace the battery module.
Minimum Capacity Before
Return from Shutdown
0 percent • 0%
• 15%
• 30%
• 45% • 60%
• 75%
• 90% Specify the percentage to which battery module(s) will be
charged following a low battery shutdown before powering
connected equipment.
Voltage Sensitivity High sensitivity High sensitivity
Medium sensitivity
Low sensitivity The UPS detects and reacts to line voltage distortions by
transferring to battery operation to protect the connected
equipment.
In situations of poor power quality, the UPS may frequently
transfer to battery operation. If the connected equipment can
operate normally under such conditions, reduce the
sensitivity setting to conserve battery capacity and service
life.
Alarm Delay Control Enable • Enable
• Mute
• Disable Mute ongoing alarms or disable all alarms permanently.
Shutdown Delay 90 seconds • 0 s
• 90 s
• 180 s
• 270 s • 360 s
• 450 s
• 540 s
• 630 s Set the interval between the time when the UPS receives a
shutdown command and actual shutdown.
