Bulletin 1400
Power Monitoring Products
Instruction Sheet
4
3. Install the new card as follows:
a.. Insert the communications card into the communications port
insuring that the communications card is oriented such that it will
mate properly with the edge connector on the main board inside the
Powermonitor Display/Block case.
Important: The card is polarized to ensure installation in the correct
orientation.
b.. Align the holes in the mounting plate of the card with the mounting
holes in the Powermonitor Module rear cover while lowering the
card towards its seating. The installer will be able to feel when the
card has found the correct alignment with the edge connector.
c.. Once the board is resting in proper alignment on the edge
connector, carefully press down to plug the card into the edge
connector.
d.. Install the four mounting screws through the mounting plate to
secure the card in position.
e.. Make all necessary communications connections to the
communications card. Communications connection information
can be found in Chapter 2 of Publication 1400–5.2, “Bulletin 1400
Power Monitor Installation and Operation” manual.
f.. The card is now ready for use.
INPUT & OUTPUT RATINGS
Te in l St i
Torque 5 lb-in (0.56 Nm) Torque
Terminal Strip
Maximum Wire 14 AWG, 2.5 mm 2 , 75
°
C CU Wire Only
Operating Temp. 0
°
C to 50
°
C (32
°
F to 122
°
F) ambient air temperature range
Storage Temp. –30
°
C to + 70
°
C (–22
°
F to 158
°
F)
Humidity 5 to 95 percent, non–condensing
Isolation 500 Volts RMS
RS-232/RS-485
Baud Rate
300 to 19,200 Baud
Remote I/O
Baud Rate
57.6kBaud, 115kBaud, 230kBaud
Energy Class Class 2 Energy Limited
Reinstalling (or Field
Retrofitting) the
Communications Card
(continued)
Specifications
