Rockwell Automation 931U-C9A2C-OP Active Converter, Universal User Manual
Page 75
75
8. Salvare le modifiche su disco come registrazione delle modifiche
apportate.
Schermata principale
Campi
Descrizione
ID Tag
Campo definito dall'utente (ad es., PT1015-2)
User reference
Campo definito dall'utente (ad es., cuscinetto pompa PT1015)
Schermata di immissione
Impostare il tipo di input premendo il tasto appropriato - verranno
visualizzati i campi rilevanti (come rappresentato sotto).
Campi
Descrizione
Engineering unit
Imposta le unità usate per le impostazioni di ingresso basso ed alto.
Input Low
Il valore inserito corrisponde ad un'uscita ‘zero’ (4 mA).
Input High
Il valore inserito corrisponde all'uscita ‘massima’ (20 mA).
Damping factor
Imposta il coefficiente di smorzamento per il filtro digitale incorporato.
Accetta valori compresi tra 1 e 99.
# of samples
Il numero di campioni medio per ogni misurazione. L'effetto di questa impo-
stazione dipende dal tipo di ingresso. L'impostazione normale è circa 50.
